ZG100 Z-Wave Voice Hub
Benefits:
- Compact size, easy installation
- Z-Wave standard protocols
- Support Z-Wave encryption
- Plug and play
- Z-Wave signal extender
Download
Application
| Main | |
|---|---|
| CPU | Dual-core Xtensa 32-bit LX6 MCU, Ultra low power co-processor |
| Memory | ROM: 448 KiB, SRAM: 512 KiB RTC SRAM: 8 KiB, eFuse: 1 Kibit Embedded flash: 4 MiB, External flash |
| Wireless | Wi-Fi 802.11 b/g/n/e/I (802.11n, up to 150Mbps) Z-Wave 908.42 MHZ (US), 868.42 MHz(EU), 922.5 MHz (JP) |
| Security | Z-Wave encryption |
| Interface | Pairing button |
| Power | micro USB 5VDC, 2A |
| Temperature | Operation: 10~60°C, storage: -40~85°C |
| Dimension | 65(L) x 65(W) x 18(H) mm |
Ordering Number
ZG100-US
ZG100-EU
ZG100-JP
